MASKLESS LITHOGRAPHY UV Direct Laser Writer (SYSTEM)

Maskless lithography enables nanopatterning at will, without the need for slow and expensive photomask. This convenience is especially useful for research and rapid prototyping use. Our system compliments the existing benefits by bringing it to the desktop without any compromise in performance.

瑆创科技开发的无掩模紫外光刻机可以设计任何您想要的纳米图形,而无需昂贵的光刻板。瑆创科技的这款产品能在实现优越的光刻性能的同时,保证低成本以及更便捷的用户体验。


The Beam Engine focuses a UV laser beam into a diffraction-limited spot and scans the spot to expose any arbitrary pattern on a photoresist. To expose large wafers, precision steppers move the wafer and allows multiple exposures to be stitched. The Beam Engine is capable of producing features smaller than (CD) 0.8µm across a 5” wafer.

光束引擎将紫外激光束聚焦到衍射极限点并曝光光刻胶上的任何图案。对大尺寸晶圆,设备能实现精准的步进式光刻。光束引擎具有能够在 5 英寸晶圆上产生小于 (CD) 0.8µm 的特征。


* We have a new option for you now - the BEAM Lite. At a lower price, you can get the best-fitting product. Contact us for more details.

* 瑆创新推出的Beam Lite,可以根据需要自由组合,为用户带来更灵活更实惠的最优选项。请即联系我们获取最新资讯。



Compact 袖珍

Full-featured maskless lithography, smaller than a desktop computer.

全功能无掩模光刻机,比台式电脑还小,价格更实惠。

Powerful 强大

Sub-micron resolution while exposes a writefield in less than two seconds.

拥有亚微米分辨率,在不到两秒的时间内完成一个曝光图案的写入。

Ultrafast Autofocus 超快自动对焦

Piezo actuators reach focus in less than a second when combined with our closed-looped focus optics.

当与我们的闭环聚焦光学器件结合使用时,压电致动器在不到一秒的时间内完成聚焦。

No-fuss Multilayer 毫不费力的多层对齐Semi-automatic alignment allows multilayer alignment to be completed within minutes.

几分钟内实现半自动多层对准。





Request for Demo or Sample Measurement

Please contact us: info@simtrum.com

想获取产品演示或样品测量请即电邮我们

Product Brochures Download

   产品目录 下载

Product Specification


ParametersBEAMBEAM Lite
Minimum Linewidth最小线宽

2 µm guaranteed,  0.8 µm achievable (0.8µm可实现)

3 µm guaranteed,  2 µm achievable (2µm可实现)

Minimum Pitch 最小间距

1.6 µm achievable(可达到1.6 µm)4 µm achievable (可达到4 µm)

Exposure Time 曝光时间

< 2 s for 1 writefield(1个图案<2s)

Maximum Writefield 最大写成

400 µm ✕ 400 µm800 µm ✕ 800 µm

Laser Power 激光能量

40mW(Customizble可定制)

Laser Wavelength 激光波长

405 nm375/405 nm

Laser Galvo 激光振镜

Step Size 步径

8 nm

Repeatability 重复性

< 100 nm (static)

Speed 速度

up to 200 mm/s

Motorized Stepper

电动平台

Encoder Resolution 编辑器分辨率

0.1 µm

Stage Repeatability (1σ)载物台重复性

Better than 0.3 µm (优于 0.3 µm)

Movement Area 移动区域

120 mm ✕ 120 mm

Largest Sample Size 最大样本尺寸

130 mm ✕ 130 mm (> 5”)

Wafer Alignment 晶圆对齐

Multilayer processes supported  支持多层工艺

Single-layer processes supported*   支持单层工艺*

Accepted File Formats 接受的文件格式.bmp, .png, .tiff, .gds, Custom shapes can directly be drawn   in software. 自定义形状可以直接在软件中绘制

Software 软件

Patterning 图案

Nanyte BEAM Xplorer

Design 设计

KLayout (most powerful最强大),   MS Paint/Powerpoint (rapid prototyping快速原型设计)

Weight 重量

Lighter than 20 kg 少于20公斤

System Size 系统尺寸

330 ✕ 310 ✕ 340 mm

* For more information about upgrading to Multilayer Processes, please contact us. 可升级为支持多层工艺,请联系我们了解更多资讯。





Front View









Back View




Modular optics.jpg

    Modular Laser Head


      Swappable optics minimizes downtime and increases upgradeability.

      可更换的光学元件可最大限度地减少停机时间并提高可升级性。


      Customization options are available for different wavelengths and write

      field sizes. Contact us info@simtrum.comfor more info.

      定制选项可用于不同的波长和写场大小。联系我们 info@simtrum.com

      了解更多信息 。




System Requirements


Power 功率

BEAM opeartes on 100-240 VAC 50-60j Hz. Line voltage and frequency are automatically sensed; therefore, no swithces are to be set. Check that the operating voltagein your area is compatible. BEAM 在 100-240 VAC 50-60j Hz 上运行。 自动感应线路电压和频率; 因此,无需设置任何开关。 检查您所在地区的工作电压是否兼容。


Location 放置环境

●  Indoor, dust free, near-non-conductive pollution (degree 2 of EN61010-1:2010) 室内、无尘、近非导电污染(EN61010-1:2010 2 级)

●  Tabletop vibration should be kept under VC-A (50 um/s) 桌面振动应保持在 VC-A (50 um/s) 以下

●  Cleanroom environment is optional 非超净间环境下可使用 (Vibration Reference link)

●  Equipment must be shaded from indirect sunlight 设备必须避免阳光直射

●  Relative humidity < 80% (no condensation) 相对湿度 < 80%(无冷凝)


Measurement Example


Split-ring resonator arrays. The distance on the right is 1.5 µm (arrow),

separation distance on the left is 2 µm. The outer ring is 80 µm across.

开环谐振器阵列。右侧的分离距离为1.5µm (箭头),左侧的分离距离为 2 µm。

外圈直径为 80 µm。


Array of resist micropatterns on silicon substrate. Each cell is 50 ✕ 63 µm,

with 3 µm spacing between adjacent patterns. Resist used: AZ5214E

硅衬底上的光刻胶微图案阵列。 每个单元为 50 × 63 µm,相邻图案之间的间距为

 3 µm。 使用的光刻胶:AZ5214E




0.8 µm tapered middle section with 20 ✕ 90 µm contact pads on the side.

Resist used: AZ5214E

0.8 µm 锥形中间部分,侧面有 20 ✕ 90 µm 接触电极。 使用的光刻胶:AZ5214E



Software Features

The included software makes quick work of any patterning job; just load, align and expose. Navigation is similar to CNC systems.

During multilayer exposures, the GDS pattern is overlaid for visualization. The control GUI (left window) has a minimap of the loaded GDS that allows navigation to any area on the wafer with 1-click.

随附的软件可以快速完成任何图案工作; 只需加载、对准和曝光。 导航类似于 CNC 系统。在多层曝光期间,GDS 图案被覆盖以进行可视化。 控制 GUI(左窗口)有一个加载的 GDS 的小地图,允许通过一键导航到晶圆上的任何区域。


Xplorer Main Window
Camera Window

Acts as a minimap of the entire sample stage. Loaded patterns and exposed areas can be viewed. The black bos shows the regin that the BEAM ENGINE is currently at. The live video stream on the camera window also corresponds to the same area.

充当整个样本阶段的小地图。 可以查看加载的图案和暴露区域。 黑色 bos 显示 BEAM ENGINE 当前所在的区域。 摄像头窗口上的实时视频也对应相同的区域。


The camera window shows a live stream of what the BEAM ENGINE is looking at. The camera window also plays an important role during alignment, where the chosen alignment features appear overlaid on the amera stream.

摄像头窗口显示 BEAM ENGINE 下方的图案。 相机窗口在对齐过程中也起着重要作用,其中选定的对齐特征显示在 amera 流上。


Patterning Processing


NANYTE BEAM was desinged so that the least number of steps are necessary to do a full exposure. Depending on the complexity of the patteming job, it is possible to load, align and expose a pattern onto a wafer in under 3 minutes. the flow of the entire patterning process is as shown below:

NANYTE BEAM 的设计使完全曝光所需的步骤最少。 根据图案化工作的复杂性,可以在 3 分钟内将图案加载、对齐和曝光到晶圆上。 整个图案化工艺流程如下图所示:
