光学接触MIR零阶四分之一波片

PRODUCTS In this catergory have specification sheets and brochures attached. Please do feel free to explore and drop us an email if we can be of assistance. Alternatively, visit the Request a quotation tab for ordering information.














General Specifications

Type

Optically Contacted Middle Infrared Zero Order Quarter Waveplate

Material

MgF2

Retardation

λ/4

Retardation Tolerance

<λ/100

Dimensional Tolerance(mm)

+0/-0.2

Parallelism(arcsec)

<5

Clear Aperture

>11.5mm

Surface Quality

40/20

Wavefront Distortion

<λ/4@633nm

Damage Threshold(pulsed)

>1J/cm²(20ns 20Hz 1064nm)




Update Coming soon!

As our website is in Soft Launch, we are currently updating our website to reflect our full capability.

This product line’s information/specification will be updated soon. The information is available upon request.

Apologies for the inconvenience caused.

Contact Us



We are here for you!




Drop us an email at info@simtrum.com to get the Best Price today.

Want more technical information? Click Here for the professional Customized System/ Solutions.




Don't have time to search the products one by one? No worries. you can download the full range of SIMTRUM Product Line Cards.

Click it now.


Want to stay closer to the Market Dynamics and Technological Developments? Just take 5 seconds to Sign In as a member of SIMTRUM, we will bring you the most up-to-date news.

(Sign in button on the top right of the screen).



Design Wavelength (nm)

Diameter (mm)


Search Reset
Compare Model Drawings & Specs Design Wavelength (nm) Diameter (mm) Mount Diameter (mm) Availability Reference Price
(USD)
MgF2-MIRQWP-12.7-2500-M
MgF2, Middle Infrared Zero Order Quarter Waveplate, Ø= 12.7mm, AR Coating: R<0.5%@2500nm, Mount Ø= 25.4mm
250012.725.4 2-3 Weeks Request for quote
MgF2-MIRQWP-12.7-2700-M
MgF2, Middle Infrared Zero Order Quarter Waveplate, Ø= 12.7mm, AR Coating: R<0.5%@2700nm, Mount Ø= 25.4mm
12.725.4 2-3 Weeks Request for quote
MgF2-MIRQWP-12.7-2940-M
MgF2, Middle Infrared Zero Order Quarter Waveplate, Ø= 12.7mm, AR Coating: R<0.5%@2940nm, Mount Ø= 25.4mm
12.725.4 2-3 Weeks Request for quote
MgF2-MIRQWP-12.7-3500-M
MgF2, Middle Infrared Zero Order Quarter Waveplate, Ø= 12.7mm, AR Coating: R<0.5%@3500nm, Mount Ø= 25.4mm
12.725.4 2-3 Weeks Request for quote
MgF2-MIRQWP-12.7-4000-M
MgF2, Middle Infrared Zero Order Quarter Waveplate, Ø= 12.7mm, AR Coating: R<0.5%@4000nm, Mount Ø= 25.4mm
12.725.4 2-3 Weeks Request for quote
MgF2-MIRQWP-12.7-4500-M
MgF2, Middle Infrared Zero Order Quarter Waveplate, Ø= 12.7mm, AR Coating: R<0.5%@4500nm, Mount Ø= 25.4mm
12.725.4 2-3 Weeks Request for quote

MgF2-MIRQWP-12.7-4500-M - Parameter

Type
Optically Contacted Middle Infrared Zero Order Quarter Waveplate

Material
MgF2

Coating

Diameter (mm)
12.7

Thickness Tolerance (mm)
±0.2

Design Wavelength (nm)

Surface Quality
40/20

Clear Aperture
>11.5mm

Damage Threshold (pulsed)
>1J/cm²(20ns 20Hz 1064nm)

Dimensional Tolerance (mm)
+0/-0.2

Wavefront Distortion
<λ/4@633nm

Parallelism (arcsec)
<5

Retardation
λ/4

Retardation Tolerance
<λ/100

Mount Diameter (mm)
25.4

MgF2-MIRQWP-12.7-4000-M - Parameter

Type
Optically Contacted Middle Infrared Zero Order Quarter Waveplate

Material
MgF2

Coating
R<0.5% @4000nm

Diameter (mm)
12.7

Thickness Tolerance (mm)
±0.2

Design Wavelength (nm)

Surface Quality
40/20

Clear Aperture
>11.5mm

Damage Threshold (pulsed)
>1J/cm²(20ns 20Hz 1064nm)

Dimensional Tolerance (mm)
+0/-0.2

Wavefront Distortion
<λ/4@633nm

Parallelism (arcsec)
<5

Retardation
λ/4

Retardation Tolerance
<λ/100

Mount Diameter (mm)
25.4

MgF2-MIRQWP-12.7-3500-M - Parameter

Type
Optically Contacted Middle Infrared Zero Order Quarter Waveplate

Material
MgF2

Coating

Diameter (mm)
12.7

Thickness Tolerance (mm)
±0.2

Design Wavelength (nm)

Surface Quality
40/20

Clear Aperture
>11.5mm

Damage Threshold (pulsed)
>1J/cm²(20ns 20Hz 1064nm)

Dimensional Tolerance (mm)
+0/-0.2

Wavefront Distortion
<λ/4@633nm

Parallelism (arcsec)
<5

Retardation
λ/4

Retardation Tolerance
<λ/100

Mount Diameter (mm)
25.4

MgF2-MIRQWP-12.7-2940-M - Parameter

Type
Optically Contacted Middle Infrared Zero Order Quarter Waveplate

Material
MgF2

Coating

Diameter (mm)
12.7

Thickness Tolerance (mm)
±0.2

Design Wavelength (nm)

Surface Quality
40/20

Clear Aperture
>11.5mm

Damage Threshold (pulsed)
>1J/cm²(20ns 20Hz 1064nm)

Dimensional Tolerance (mm)
+0/-0.2

Wavefront Distortion
<λ/4@633nm

Parallelism (arcsec)
<5

Retardation
λ/4

Retardation Tolerance
<λ/100

Mount Diameter (mm)
25.4

MgF2-MIRQWP-12.7-2700-M - Parameter

Type
Optically Contacted Middle Infrared Zero Order Quarter Waveplate

Material
MgF2

Coating

Diameter (mm)
12.7

Thickness Tolerance (mm)
±0.2

Design Wavelength (nm)

Surface Quality
40/20

Clear Aperture
>11.5mm

Damage Threshold (pulsed)
>1J/cm²(20ns 20Hz 1064nm)

Dimensional Tolerance (mm)
+0/-0.2

Wavefront Distortion
<λ/4@633nm

Parallelism (arcsec)
<5

Retardation
λ/4

Retardation Tolerance
<λ/100

Mount Diameter (mm)
25.4

MgF2-MIRQWP-12.7-2500-M - Parameter

Type
Optically Contacted Middle Infrared Zero Order Quarter Waveplate

Material
MgF2

Coating

Diameter (mm)
12.7

Thickness Tolerance (mm)
±0.2

Design Wavelength (nm)
2500

Surface Quality
40/20

Clear Aperture
>11.5mm

Damage Threshold (pulsed)
>1J/cm²(20ns 20Hz 1064nm)

Dimensional Tolerance (mm)
+0/-0.2

Wavefront Distortion
<λ/4@633nm

Parallelism (arcsec)
<5

Retardation
λ/4

Retardation Tolerance
<λ/100

Mount Diameter (mm)
25.4

MgF2-MIRQWP-12.7-4500-M - Download

MgF2-MIRQWP-12.7-4000-M - Download

MgF2-MIRQWP-12.7-3500-M - Download

MgF2-MIRQWP-12.7-2940-M - Download

MgF2-MIRQWP-12.7-2700-M - Download

MgF2-MIRQWP-12.7-2500-M - Download
