方解石

LBO Nonlinear Optical Crystal.jpg

Calcite crystal is one of the three different mineral form of calcium carbonate and it is also the most stable. It is a negative uniaxial crystal with very high birefringence, wide spectral transmission and moderate refractive index.


Its extreme birefringence gives it both negative and positive relief, based on orientation. Calcite is suitable for polarizers in the VIR range, Glan-Thompson Polarizers and Glan laser polarizers.





General Specifications

Material

Calcite

Dimension Tolerance(mm)

±0.1

Surface Quality

10/5

Flatness

<λ/6@633nm

Wavefront Distortion

λ/8

Parallelism(arcsec)

<20

Damage Threshold(pulsed)

1.5-2.0MW/cm2











We are here for you!




Drop us an email at info@simtrum.com to get the Best Price today.

Want more technical information? Click Here for the professional Customized System/ Solutions.




Don't have time to search the products one by one? No worries. you can download the full range of SIMTRUM Product Line Cards.

Click it now.


Want to stay closer to the Market Dynamics and Technological Developments? Just take 5 seconds to Sign In as a member of SIMTRUM, we will bring you the most up-to-date news.

(Sign in button on the top right of the screen).



Dimension (mm)


Search Reset
Compare Model Drawings & Specs Coating Dimension (mm) Thickness (mm) Availability Reference Price
(USD)
C-BFC-10-0.5
Calcite, Birefringent Crystals, Dimension=10x10x0.5mm, AR coating: 650-850nm
10x100.5 2-3 Weeks Request for quote

C-BFC-10-0.5 - Parameter

Material
Calcite

Coating

Thickness Tolerance (mm)
± 0.1

Surface Quality
10/5

Clear Aperture
>90%

Dimension (mm)
10x10

Dimensional Tolerance (mm)
±0.1

Thickness (mm)
0.5

Flatness
<λ/6@633nm

Wavefront Distortion
λ/8

Parallelism (arcsec)
<20

C-BFC-10-0.5 - Download

Accessories

Compare Model Drawings & Specs Availability Reference Price
(USD)
