多带通荧光滤光片 | 瑆创光学电子商店

多带通荧光滤光片
多波段滤光片组多色荧光标记和成像在生命科学和医学领域具有 非常重要和广泛的应用。传统方法是使用​​​​​​​​​​​​​​​​​​​​​​​​ 多个单色和滤光片组分别收集相应的荧光图像,然后将多幅图像叠加成一幅多色图像。

这种方法提供最佳信噪比最大限度减少通道泄漏缺点速度并且避免图像偏移因此产生漂移使用ChromaT系列滤光片为了满足高速多色荧光成像需求Chroma磁控溅射镀膜过程通过精细设计控制实现复杂光谱特征从而可见区域实现多达五个通道波段滤波器

Chroma T系列波段滤光片具有透过率截止深度光谱特点可以满足高速成像需求同时提高优异信噪比

根据激发发射类型 ET系列波段滤光片重新划分四个类别满足高速多色成像需求 不同 类型滤波配置它们各自优点示例光谱安装方法如下
滤片组
激发滤光片
二向色镜
发射机
优点
 全套多波段套装 - 多波段激励 & 多波段发射器1 多频带
多频带
多频带  最快成像速度&同时多色成像
 Pinkel 多波段套装 - 单波段激励 & 多波段发射器2 单波段 多频带 多频带  光损伤小,信噪比更好,串色更少
 多波段激励和单波段发射机2 多频带 多频带 单波段  适用于多波长 LED 或激光光源,具有最小的渗透性
 Sedat 多波段套装 - 单波段激励和单波段发射器2 单波段 多频带 单波段  光损小,信噪比最好,色散最小

1.激发片、发射片、二向色镜安装在显微镜立方体内;

2.需另行配置滤镜轮

多波段激励和多波段发射器

单波段激发&多波段发射

多波段发射源&单波段激发



单波段激励&单波段激励










ET 系列 -多波段滤光片多波段多波段激发  多波段 发射器
滤波片 典型荧光团 频谱图
BFP/DAPI CFP FITC/GFP YFP Cy3/TRITC mCherry Cy5 Cy7
59004
59009
59017
59022
59026
69000
69002
69008
69010
89401
89402
89403

ET 系列 Pinkel多波段(波段激发  多波段 发射器)

Filter set 典型荧光团 频谱图
BFP/DAPI CFP FITC/GFP YFP Cy3/TRITC mCherry Cy5 Cy7
59204
59217
59222
59207
69300
69302
69308
89400

ET 系列 -多波段滤光片 多波段激发 波段 发射器
Filter set 典型荧光团
频谱图
BFP/DAPI CFP FITC/GFP YFP Cy3/TRITC mCherry Cy5 Cy7
89404
89405

ET 系列 Sedat 多波段(单波段激发 波段 发射器
Filter set 典型荧光团
频谱图
BFP/DAPI CFP FITC/GFP YFP Cy3/TRITC mCherry Cy5 Cy7
89000
89002
89006
89007

89013
89014

89016
89017

89019
89021

89022
89903



*注意价格不包括任何运费、税费或清关费。


ET 系列 - 比率测量的滤光片组
滤片组 激发滤光片
(CWL/FWHM)nm
二向色镜
(50% cut-on)nm
发射机
(CWL/FWHM)nm
典型荧光团 光谱透射曲线
79001

单波段:Ex1: 340/11; Ex2: 380/11

400 510/80 Fura-2/Ca2+ - 游离,Fura-2/Ca2+ - 饱和,SBFI/Na+ -游离,SBFI/Na+ -饱和







79002

单波段:Ex1: 340/11; Ex2: 380/11;Ex3: 436/20; Ex4: 495/10

510 560/80 Fura 2/BCECF
79003

单波段:Ex1: 340/11; Ex2: 380/11;Ex3: 555/25

多波段:463; 575 多波段:501/60; 612/63 Fura 2/TRITC
79004

单波段:Ex1: 340/11; Ex2: 380/11;Ex3: 470/40

495 535/70 Fura 2/GFP
79005

单波段:Ex1: 436/20; Ex2: 495/10

510 540/40 BCECF/pH 5.2,BCECF/pH 9.0
79006 365/10 387 单波段:Em1: 405/30; Em2: 485/25 Indo-1/Ca2+ -游离,Indo-1/Ca2+ -饱和
79009 500/20 570 单波段:Em1: 585/20; Em2: 640/20 SNARF with 500nm,激发
79010 550/20 570 单波段:Em1: 585/20; Em2: 640/20 SNARF with 550nm,激发

*注意价格不包括任何运费、税费或清关费。


我们在这里为您服务!





给我们发电子邮件 info@simtrum.com 以获得今天最优惠的价格。   想要更多的技术信息?点击这里 获取专业定制系统/解决方案。




没有时间逐个搜索产品?不用担心。您可以下载全系列的瑆创产品线卡现在点击它。



想要更接近市场动态和技术发展吗?只需花5秒钟作为会员登录,我们将为您带来最新的新闻。​(屏幕右上方的登录按钮)



Search Reset
Compare Model Drawings & Specs Availability Reference Price
(USD)
59004 Filter Set
59004-ET-FITC/TRITC,Multiband Filter Set (Full Multiband, Multiband Excitation & Multiband Emitter ),Filters can be purchased separately
4-6 Weeks $1050.00
59009 Filter Set
59009-ET-FITC/CY3 ,Multiband Filter Set (Full Multiband, Multiband Excitation & Multiband Emitter ),Filters can be purchased separately
4-6 Weeks $1050.00
59017 Filter Set
59017-ET-ECFP/EYFP,Multiband Filter Set (Full Multiband, Multiband Excitation & Multiband Emitter ),Filters can be purchased separately
4-6 Weeks $1050.00
59022 Filter Set
59022-ET-EGFP/mCherry (or FITC/TxRed),Multiband Filter Set (Full Multiband, Multiband Excitation & Multiband Emitter ),Filters can be purchased separately
4-6 Weeks $1050.00
59026 Filter Set
59026-ET-EYFP/mCherry,Multiband Filter Set (Full Multiband, Multiband Excitation & Multiband Emitter ),Filters can be purchased separately
4-6 Weeks $1050.00
69000 Filter Set
69000-ET-DAPI/FITC/TRITC ,Multiband Filter Set (Full Multiband, Multiband Excitation & Multiband Emitter ),Filters can be purchased separately
4-6 Weeks $1250.00
69002 Filter Set
69002-ET-DAPI/FITC/Texas Red®,Multiband Filter Set (Full Multiband, Multiband Excitation & Multiband Emitter ),Filters can be purchased separately
4-6 Weeks $1250.00
69008 Filter Set
69008-ET-ECFP/EYFP/mCherry,Multiband Filter Set (Full Multiband, Multiband Excitation & Multiband Emitter ),Filters can be purchased separately
4-6 Weeks $1250.00
69010 Filter Set
69010-ET-DAPI/FITC/Cy3,Multiband Filter Set (Full Multiband, Multiband Excitation & Multiband Emitter ),Filters can be purchased separately
4-6 Weeks $1250.00
89401 Filter Set
89401-ET-DAPI/FITC/TRITC/CY5 Quad,Multiband Filter Set (Full Multiband, Multiband Excitation & Multiband Emitter ),Filters can be purchased separately
4-6 Weeks $1500.00
89402 Filter Set
89402-ET- 391-32/479-33/554-24/638-31 Multi LED set,Multiband Filter Set (Full Multiband, Multiband Excitation & Multiband Emitter ),Filters can be purchased separately
4-6 Weeks $1550.00
89403 Filter Set
89403-ET-436-28/506-21/578-24/730-40 Multi LED set,Multiband Filter Set (Full Multiband, Multiband Excitation & Multiband Emitter ),Filters can be purchased separately
4-6 Weeks $1550.00
59204 Filter Set
59204-ET-FITC/TRITC with single band exciters,Multiband Filter Set (Full Multiband, Multiband Excitation & Multiband Emitter ),Filters can be purchased separately
4-6 Weeks $1350.00
59217 Filter Set
59217-ET-ECFP/EYFP with single band exciters,Filters can be purchased separately
4-6 Weeks $1350.00
59222 Filter Set
59222-ET- EGFP/mCherry (or FITC/TxRed) with single band exciters,Filters can be purchased separately
4-6 Weeks $1350.00
59207 Filter Set
59207-ET-CY3/Cy5 with single band exciters,Filters can be purchased separately
4-6 Weeks $1350.00
69300 Filter Set
69300-ET-DAPI/FITC/TRITC with single band exciters,Filters can be purchased separately
4-6 Weeks $1700.00
69302 Filter Set
69302-ET-DAPI/FITC/Texas Red® with single band exciters,Filters can be purchased separately
4-6 Weeks $1700.00
69308 Filter Set
69308-ET-ECFP/EYFP/mCherry with single band exciters,Filters can be purchased separately
4-6 Weeks $1700.00
89400 Filter Set
89400-ET-DAPI/FITC/TRITC/Cy5 Quad with Single Band,Filters can be purchased separately
4-6 Weeks $2350.00
89405 Filter Set
89405-ET-436-28/506-21/578-24/730-40 Multi LED set with single band emitters,Filters can be purchased separately
4-6 Weeks $2300.00
89404 Filter Set
89404-ET-391-32/479-33/554-24/638-31 Multi LED set with single band emitters,Filters can be purchased separately
4-6 Weeks $2300.00
89000 Filter Set
89000 ET Series - Sedat Multiband,Typical fluorophores BFP/DAPI,FITC/GFP,Cy3/TRITC,Filters can be purchased separately
4-6 Weeks $2850.00
89002 Filter Set
89002 ET Series - Sedat Multiband,Typical fluorophores CFP,YFP,Filters can be purchased separately
4-6 Weeks $1600.00
89006 Filter Set
89006 ET Series - Sedat Multiband,Typical fluorophores CFP,YFP,mCherry,Filters can be purchased separately
4-6 Weeks $2200.00
89022 Filter set
89022 ET Series - Sedat Multiband,Typical fluorophores Cy3/TRITC,Cy5,Filters can be purchased separately
4-6 Weeks $1550.00
89013 Filter set
89013 ET Series - Sedat Multiband,Typical fluorophores BFP/DAPI,FITC/GFP,Cy3/TRITC,Filters can be purchased separately
4-6 Weeks $2200.00
89014 Filter set
89014 ET Series - Sedat Multiband,Typical fluorophores BFP/DAPI,FITC/GFP,mCherry,Filters can be purchased separately
4-6 Weeks $2200.00
89016 Filter set
89016 ET Series - Sedat Multiband,Typical fluorophores FITC/GFP,Cy3/TRITC,Cy5,Filters can be purchased separately
4-6 Weeks $2220.00
89017 Filter set
89017 ET Series - Sedat Multiband,Typical fluorophores FITC/GFP,mCherry,Filters can be purchased separately
4-6 Weeks $1600.00
89019 Filter set
89019 ET Series - Sedat Multiband,Typical fluorophores FITC/GFP,Cy3/TRITC,Filters can be purchased separately
4-6 Weeks $1600.00
89021 Filter set
89021 ET Series - Sedat Multiband,Typical fluorophores BFITC/GFP,mCherry,Filters can be purchased separately
4-6 Weeks $1600.00
89007 Filter set
89007 ET Series - Sedat Multiband,Typical fluorophores CFP,YFP,Cy3/TRITC,Filters can be purchased separately
4-6 Weeks $2200.00
89903 Filter set
89903 ET Series - Sedat Multiband,Typical fluorophores BFP/DAPI,CFP,YFP,mCherry,Cy5,Filters can be purchased separately
4-6 Weeks $3850.00
79001 Filter Set
79001-ET Series Ratio Measurement Filter Sets,Excitation tablets(CWL/FWHM):Single-band:Ex1: 340/11; Ex2: 380/11 nm ,Dichroic mirrors(50% cut-on) 400 nm,Transmitters(CWL/FWHM)510/80
4-6 Weeks $1150.00
79002 Filter Set
79002-ET Series Ratio Measurement Filter Sets,Excitation tablets(CWL/FWHM):Single-band:Single-band:Ex1: 340/11; Ex2: 380/11;Ex3: 436/20; Ex4: 495/10 nm ,Dichroic mirrors(50% cut-on) 510 nm,Transmitters(CWL/FWHM)560/80
4-6 Weeks $2050.00
79003 Filter Set
79003 ET Series Ratio Measurement Filter Sets,Excitation tablets(CWL/FWHM):Single-band:Ex1: 340/11; Ex2: 380/11;Ex3: 555/25 nm ,Dichroic mirrors(50% cut-on) Multi-band:463; 575 nm,Transmitters(CWL/FWHM) Multi-band:501/60; 612/63 nm,
4-6 Weeks $1850.00
79004 Filter Set
79004-ET Series Ratio Measurement Filter Sets,Excitation tablets(CWL/FWHM):Single-band:Ex1: 340/11; Ex2: 380/11;Ex3: 470/40nm ,Dichroic mirrors(50% cut-on) 495 nm,Transmitters(CWL/FWHM)535/70 nm
4-6 Weeks $1700.00
79005 Filter Set
79005 ET Series Ratio Measurement Filter Sets,Excitation tablets(CWL/FWHM):Single-band:Ex1: 436/20; Ex2: 495/10 nm ,Dichroic mirrors(50% cut-on) 510 nm,Transmitters(CWL/FWHM)540/40 nm
4-6 Weeks $1350.00
79006 Filter Set
79006 ET Series Ratio Measurement Filter Sets,,Excitation tablets(CWL/FWHM):365/10 nm ,Dichroic mirrors(50% cut-on) 387 nm,Transmitters(CWL/FWHM)Single-band:Em1: 405/30; Em2: 485/25 nm
4-6 Weeks $1250.00
79009 Filter Set
79009 ET Series Ratio Measurement Filter Sets,,Excitation tablets(CWL/FWHM):500/20 nm ,Dichroic mirrors(50% cut-on) 570 nm,Transmitters(CWL/FWHM)Single-band:Em1: 585/20; Em2: 640/20 nm
4-6 Weeks $1200.00
79010 Filter Set
79010-ET Series Ratio Measurement Filter Sets,Excitation tablets(CWL/FWHM):550/20 nm ,Dichroic mirrors(50% cut-on) 570 nm,Transmitters(CWL/FWHM)Single-band:Em1: 585/20; Em2: 640/20 nm
4-6 Weeks $1200.00
