单带通荧光滤光片

单波段滤光片组由一组滤光片组成,每个滤光片设计用于传输(或阻挡)特定波长(或非常窄的波长范围)的光。这些类型的滤光片在光学实验、摄影、天文观测和各种光学设备中极为重要,可确保只有特定波长的光才能通过。单波段滤光片组的典型应用是 宽视野显微镜。

AT系列定位为“高性价比”,ET系列则定位为高端系列。Chroma的磁控溅射是一种高端镀膜工艺,利用磁场控制等离子体中的离子,使镀膜材料均匀、精确地沉积在基材上。AT和ET系列均具有高透过率(允许大量特定波长的光通过)、高截止深度(有效阻挡非目标波长的光)和高陡度(在目标波长的边界提供锐利的滤波效果)的特点。

您可以根据您的具体需求选择购买全套过滤器或单独的过滤器!


AT和ET系列的主要区别如下:
产品范围 透光率 截止深度 光谱陡度 零点漂移
AT 系列 >/= 平均 92% OD5 绝对值 </= 2% 不保证
ET 系列 >/= 平均 92% OD6 平均值 </= 1% 保证


                                                AT系列GFP带通滤光片39002 )                                                          ET系列GFP带通滤光片49002 )

AT 系列 - 单波段带通滤光片组

39000 系列

Chroma 的 39000 系列由我们的标准 AT 溅射带通滤光片组组成。这些价格实惠的滤光片组提供与我们的高级 ET 滤光片组相同的耐用性和使用寿命,透射率 >90%,并享有 Chroma 的终身保修。


AT 滤光片组是常规荧光检测和分析的完美选择,也是大多数需要准确颜色辨别和出色带外阻断的应用的理想选择。对于零像素移位图像配准以及需要最高信号强度的应用,请参考我们的 ET 滤光片。

滤片组 激发滤光片
(CWL/FWHM)nm
二向色镜
(50% cut-on)nm
发射机
(CWL/FWHM)nm
典型荧光团 光谱透射曲线
39000 375/28 415 460/50 DAPI/Hoechst/Alexa Fluor 350TM
39001 435/20 455 480/30 ECFP/AmCyan/Cerulean/Atto 425
39002 480/30 505 535/40 EGFP/FITC/Cy2TM/Alexa Fluor 488TM/Atto 488
39003 495/20 515 540/30 EYFP/Citrine/Rhodamine 123/Alexa Fluor 514™
39004 540/25 565 605/55 Cy3™/TRITC/DsRed/TAMRA
39005 540/25 565 620/60 AsRed2/Propidium IodideTRITC-red-shifted
39006 575/30 605 640/60 ROX/Texas Red®/mCherry/Alexa Fluor 594TM
39007 620/50 655 690/50 Cy5™/Alexa Fluor 647TM/Atto 647N/Quasar® 670
39008 420/40 455 535/40 Lucifer Yellow
39009 480/30 505 620/60 Acridine Orange/Di-8-ANEPPS
39010 560/40 600 635/60 ROX/Texas Red®/mCherry/Alexa Fluor 594TM

AT 系列 - 单波段长通滤光片组
19000 系列
Chroma 的 19000 系列长通滤光片组由我们价格实惠的 AT 滤光片组成。长通滤光片组用于许多临床和工业应用。这些滤光片组与我们的 39000 系列类似,但使用长通发射滤光片而不是带通发射滤光片。这提供了多功能性,允许检测具有重叠吸收光谱的各种荧光染料,并提供高信号强度。这些套件享有 Chroma 的终身保修。

长通套件无法可靠地区分任何给定样本中的多个荧光探针。对于具有多种荧光染料的样本,请参考我们的带通滤光片组,例如 39000 AT 或 49000 ET 系列滤光片组。

滤片组 激发滤片
(CWL/FWHM)nm
二向色镜
(50% cut-on)nm
发射机
(CWL/FWHM)nm
典型荧光团 光谱透射曲线
19000 375/28 415 435 DAPI/钙荧光白
19001 420/40 455 465 水蓝色
19002 480/30 505 515 绿色荧光蛋白/异硫氰酸
19004 540/25 565 575 TRITC/Cy3
19006 560/40 600 610 德克萨斯红
19008 450/50 485 495 金胺
19010 480/30 505 600 FM 1-43/叶绿素
19011 405/30 440 450 香豆素/太平洋蓝
19012 375/28 415 515 荧光金/钙荧光白
AT Series - Quantum dot (Qdot) filter sets
39100 系列
39100 系列是 AT 滤光片组,专为与 Qdots 等纳米晶体配合使用而设计。这些晶体是用半导体材料制成的无机纳米颗粒,具有量子力学特性,因此具有独特的荧光特性。各种 Qdots 可能都受相同紫外或 UV 波长的激发,但随着纳米晶体尺寸变大,荧光发射的波长会变长。

该系列中的所有组都使用相同的 AT425/50x 激发滤光片和配套的二向色滤光片,不同的发射滤光片与各种 Qdots 的发射光谱相对应。
滤片组 激发滤片
(CWL/FWHM)nm
二向色镜
(50% cut-on)nm
发射机(CWL/FWHM)nm 典型荧光团 光谱透射曲线
39101 425/50 485 525/30 Qdot 525
39102 425/50 485 545/30 Qdot 545
39103 425/50 485 565/30 Qdot 565
39104 425/50 485 585/30 Qdot 585
39105 425/50 485 605/30 Qdot 605
39106 425/50 485 625/30 Qdot 625
39107 425/50 485 655/30 Qdot 655
39108 425/50 485 705/30 Qdot 705
39109 425/50 485 800/40 Qdot 800

*注:价格不包括任何运费、税费或清关费用


ET 系列 - 单波段带通滤光片组
49000 系列
Chorma 的 49000 系列单波段组采用我们最高吞吐量的溅射涂层 (ET),可实现干涉滤光片的最高透射率。这些滤光片从峰值透射率到高光密度的过渡非常陡峭,可以最大限度地利用斯托克斯位移短的现代荧光染料的光谱特性。这是因为陡峭的过渡允许激发带和发射带之间的光谱分离非常小。

这些滤镜具有最高的硬度和耐久性,可抵御高温和高湿等环境因素,并享有 Simtrum 的终身保修。所有 ET 滤镜组均提供滤镜组之间的零像素偏移图像配准*,无需额外费用。

*需要注意的是,滤光片只是成像系统中实现完美图像配准的一个因素。所有其他组件和设备也必须配准。
滤片组 激发滤光片

(CWL/FWHM)nm
二向色镜

(50% cut-on)nm
发射机

(CWL/FWHM)nm
典型荧光团 光谱透射曲线
49000 350/50 400 460/50 DAPI/Hoechst/Alexa Fluor 350TM
49001 436/20 455 480/40 ECFP/AmCyan/Cerulean/Brilliant Violet™ 480
49002 470/40 495 525/50 EGFP/FITC/Cy2TM/Alexa Fluor 488TM/Atto 488
49003 500/20 515 535/30 EYFP/Citrine/Rhodamine 123/Alexa Fluor 514™
49004 545/25 565 605/70 Cy3™/TRITC/DsRed/TAMRA
49005 545/30 570 620/60 AsRed2/Propidium IodideTRITC-red-shifted
49006 620/60 660 700/75 Cy5™/Alexa Fluor 647TM/Atto 647N/Quasar® 670
49007 710/75 760 810/90 Cy7™/DiR/DyLight 750/Alexa Fluor 750™
49008 560/40 585 630/75 ROX/Texas Red®/mCherry/Alexa Fluor 594TM
49009 640/30 660 690/50 Cy5™/Alexa Fluor 647TM/Atto 647N/Quasar® 670
49010 546/10 560 585/40 R-phycoerythrin/mOrange2/mKO
49011 480/40 510 535/50 FITC/Cy2TM/Alexa Fluor 488TM/Atto 488
49013 445/30 470 500/40 Atto 425/mTFP1
49014 530/30 550 575/40 Alexa Fluor 532™/Cy3™/HEX/mKO/mOrange2
49015 605/50 635 670/50 Alexa Fluor 633™/Atto 633/DyLight 633
49020 480/20 495 510/20 EGFP/Azami Green/DiO/mWasabi/ZsGreen1
49021 405/20 425 460/50 DyLight 405/EBFP2/Pacific Blue/TagBFP
49022 650/45 685 720/60 Cy5.5™/Alexa Fluor 680™/Atto 680/DyLight 680
49023 500/40 525 560/50 JOE/Rhodamine 6G/Eosin/TET
49024 440/40 495 630/75 mKeima Red/DiAPulsar™ 650
49026 405/40 470 550/60 Tetracycline/Lucifer Yellow
49027 395/25 412 431/28 Brilliant™ Violet 421
49028 395/25 425 460/50 DAPI for 395nm light sources
49030 775/50 810 845/55 Indocyanine Green
49031 569/25 588 615/40 Cy3.5™/Alexa Fluor 568™/CAL Fluor® Red 590
49032 436/20 455 480/30 Brilliant™ Violet 480
ET 系列 - 单波段长通滤光片组
49000 系列
Chorma 的 49000 系列单波段组采用我们最高吞吐量的溅射涂层 (ET),可实现干涉滤光片的最高透射率。这些滤光片从峰值透射率到高光密度的过渡非常陡峭,可以最大限度地利用斯托克斯位移短的现代荧光染料的光谱特性。这是因为陡峭的过渡允许激发带和发射带之间的光谱分离非常小。

这些滤镜具有最高的硬度和耐久性,可抵御高温和高湿等环境因素,并享有 Simtrum 的终身保修。所有 ET 滤镜组均提供滤镜组之间的零像素偏移图像配准*,无需额外费用。

*需要注意的是,滤光片只是成像系统中实现完美图像配准的一个因素。所有其他组件和设备也必须配准。

滤片组

激发滤光片

(CWL/FWHM)nm

二向色镜

(50% cut-on)nm

发射机

(CWL/FWHM)nm

典型荧光团 光谱透射曲线
     49012

480/40

510

510

FITC/Cy2TM/Alexa Fluor 488TM/Atto 488

49016

545/25

562

570

Cy3™/TRITC/DsRed/TAMRA

49017

560/40

590

590

ROX/Texas Red®/mCherry/Alexa Fluor 594TM

49018

470/40

495

500

EGFP/FITC/Cy2TM/Alexa Fluor 488TM/Atto 488

49019

620/60

660

665

Cy5™/Alexa Fluor 647TM/Atto 647N/Quasar® 670

49025

350/50

400

425

DAPI/Hoechst/Alexa Fluor 350TM

49029

500/20

515

520

EYFP/Citrine/Rhodamine 123/Alexa Fluor 514™

49037

740/40

770

780

Alexa Fluor 790™/DyLight 800

*注:价格不包括任何运费、税费或清关费用


二向色分光镜(镜子)用作导光光学器件,用于反射指定范围的波长,并在指定的 AOI(通常为 45 度)处传输不同的指定范围的波长。Chroma  目录中的大多数二向色镜均适用于 45 度 AOI,如果不确定,请咨询我们。  二向色镜是落射荧光配置中使用的滤光片组的必要组件。

Chroma 制造 UltraFlat 二向色镜片,用于要求高水平表面平整度的激光应用,例如 TIRF 和其他超分辨率技术。我们提供 UltraFlat 二向色镜片,可用作单独部件或包含在组装的滤光片组中。

然而,平面二向色镜的秘诀在于它们需要在您的成像系统中保持平坦。使用夹子、弹簧或螺钉固定二向色镜的滤光块会使其失去平坦度。 Chroma  的 TIRF 和超分辨率滤光块 让您的二向色镜在显微镜中保持与我们制造时一样平坦。

我们的大多数二向色镜适用于更常规的宽场荧光应用,既没​​有也不需要高水平的表面平整度,但仍具有溅射干涉滤光片涂层的其他性能优势。

用于单波段滤光片组的二向色镜:

型号 波长(CWL):nm  一系列滤光片: 光谱透射曲线
T412lpxt 412 T412lpxt  属于以下系列:49027 - ET
AT415DC
415
AT415DC 属于以下系列:39000 - AT /19000 - AT /19012 - AT
T425lpxr 425 T425lpxr  属于以下系列:49021 - ET /49301 - ET /49028 - ET /49053 - ET
AT440DC 440 AT440DC  属于以下系列:19011 - AT
T455lp 455 T455lp  属于以下系列:49001 - ET/49052 - ET /49302 - ET/49032 - ET
T470lpxr 470 T470lpxr  属于以下系列:49013 - ET /49026 - ET
AT485DC 485 AT485DC  属于以下系列:19008 - AT /39101 - AT- Qdot /39102 - AT- Qdot /39103 - AT- Qdot/39104 - AT- Qdot /39105 - AT- Qdot /39106 - AT- Qdot /39107 - AT- Qdot /39108 - AT- Qdot /39109 - AT- Qdot
T495lpxr 495 T495lpxr  属于以下系列:49002 - ET /49020 - ET /49024 - ET /49054 - ET
T495lpxt T495lpxt 属于以下系列:49018 - ET
AT505DC 505 AT505DC 属于以下系列:39002 - AT /39009 - AT /19002 - AT /19010 - AT
T510lpxrxt 510 T510lpxrxt  属于以下系列:49012 - ET /49011 - ET
T515lp 515 T515lp  属于以下系列:49003 - ET /49029 - ET /49303 - ET
T525lpxr 525 T525lpxr  属于以下系列:49023 - ET
T550lpxr 550 T550lpxr  属于以下系列:49014 - ET
T560lpxr 560 T560lpxr  属于以下系列:49010 - ET
T562lpxr 562 T562lpxr  属于以下系列:49016 - ET
T565lpxr 565 T565lpxr  属于以下系列:49004 - ET/49305 - ET
T570lp 570 T570lp  属于以下系列:49005 - ET
T570lpxr T570lpxr  属于以下系列:79009 - ET /79010 - ET /49063 - ET
T585lpxr 585 T585lpxr  属于以下系列:49008 - ET
T588lpxr 588 T588lpxr  属于以下系列:49031 - ET
T590lpxr 590 T590lpxr  属于以下系列:49017 - ET
AT600DC 600 AT600DC  属于以下系列:39010 - AT /19006 - AT
T635lpxr 635 T635lpxr  属于以下系列:49015 - ET
AT655DC 655 AT655DC  属于以下系列:39007 - AT
T660lpxr 660 T660lpxr  属于以下系列:49006 - ET /49009 - ET /49019 - ET
T685lpxr 685 T685lpxr  属于以下系列:49022 - ET
T760lpxr 760 T760lpxr  属于以下系列:49007 - ET
T770lpxr 770 T770lpxr  属于以下系列:49037 - ET
T810lpxr 810 T810lpxr  属于以下系列:49030 - ET

我们在这里为您服务!





给我们发电子邮件 info@simtrum.com 以获得今天最优惠的价格。   想要更多的技术信息?点击这里 获取专业定制系统/解决方案。




没有时间逐个搜索产品?不用担心。您可以下载全系列的瑆创产品线卡现在点击它。



想要更接近市场动态和技术发展吗?只需花5秒钟作为会员登录,我们将为您带来最新的新闻。​(屏幕右上方的登录按钮)



Search Reset
Compare Model Drawings & Specs Availability Reference Price
(USD)
39000-Filter Set
39000-AT-Filter sets,Excitation tablets (CWL/FWHM) 375/28 nm, Dichroic mirrors(50% cut-on) 415nm,Transmitters (CWL/FWHM) 460/50 nm,Filters can be purchased separately
4-6 Weeks $575.00
39001-Filter Set
39001-AT-ECFP/Cerulean,Excitation tablets (CWL/FWHM) 435/280 nm, Dichroic mirrors(50% cut-on) 455 nm,Transmitters (CWL/FWHM) 480/30 nm,Filters can be purchased separately
4-6 Weeks $575.00
39002-Filter Set
39002-AT - EGFP/FITC/Cy2/AlexaFluor 488,Excitation tablets (CWL/FWHM) 480/30 nm, Dichroic mirrors(50% cut-on) 455nm,Transmitters (CWL/FWHM) 535/40 nm,Filters can be purchased separately
4-6 Weeks $575.00
39003-Filter Set
39003-AT – UV/DAPI Longpass,Excitation tablets (CWL/FWHM) 375/28 nm, Dichroic mirrors(50% cut-on) 415 nm,Transmitters (CWL/FWHM) 435/30 nm,Filters can be purchased separately
4-6 Weeks $575.00
39004-Filter Set
39004-AT-TRITC/Cy3/TagRFP/AlexaFluor 546,Excitation tablets (CWL/FWHM) 540/25 nm, Dichroic mirrors(50% cut-on) 565 nm,Transmitters (CWL/FWHM) 605/55 nm,Filters can be purchased separately
4-6 Weeks $575.00
39005-Filter Set
39000-AT – UV/DAPI Longpass,Excitation tablets (CWL/FWHM) 375/28 nm, Dichroic mirrors(50% cut-on) 415 nm,Transmitters (CWL/FWHM) 435/30 nm,Filters can be purchased separately
4-6 Weeks $575.00
39007-Filter Set
39007-AT-Cy5/AlexaFluor 647/Draq5,Excitation tablets (CWL/FWHM) 620/50 nm, Dichroic mirrors(50% cut-on) 655 nm,Transmitters (CWL/FWHM) 690/50 nm,Filters can be purchased separately
4-6 Weeks $575.00
39008-Filter Set
39008-A -Lucifer Yellow/Tetracycline/AlexaFluor 430,Excitation tablets (CWL/FWHM) 420/40 nm, Dichroic mirrors(50% cut-on) 455 nm,Transmitters (CWL/FWHM) 535/40 nm,Filters can be purchased separately
4-6 Weeks $575.00
39009-Filter Set
39009-AT-Acridine Orange/Di-8-ANEPPS,Excitation tablets (CWL/FWHM) 480/30 nm, Dichroic mirrors(50% cut-on) 505 nm,Transmitters (CWL/FWHM) 620/60 nm,Filters can be purchased separately
4-6 Weeks $575.00
39010-Filter Set
39010-AT–Texas Red/mCherry/AlexaFluor 594,Excitation tablets (CWL/FWHM) 560/40 nm, Dichroic mirrors(50% cut-on) 600 nm,Transmitters (CWL/FWHM) 635/60 nm,Filters can be purchased separately
4 - 6 Weeks $575.00
19000-Filter Set
19000-AT – UV/DAPI Longpass,Excitation tablets (CWL/FWHM) 375/28 nm, Dichroic mirrors(50% cut-on) 415 nm,Transmitters (CWL/FWHM) 435 nm,Filters can be purchased separately
4 - 6 Weeks $500.00
19001-Filter Set
19001-AT-Aqua Longpass,Excitation tablets (CWL/FWHM) 420/40 nm, Dichroic mirrors(50% cut-on) 455 nm,Transmitters (CWL/FWHM) 465 nm,Filters can be purchased separately
4 - 6 Weeks $500.00
19002-Filter Set
19002-AT-GFP/FITC Longpass,Excitation tablets (CWL/FWHM) 480/30 nm, Dichroic mirrors(50% cut-on) 505nm,Transmitters (CWL/FWHM) 515 nm,Filters can be purchased separately
4 - 6 Weeks $500.00
19004-Filter Set
19004-AT-TRITC/Cy3 Longpass,Excitation tablets (CWL/FWHM) 540/25 nm, Dichroic mirrors(50% cut-on) 565 nm,Transmitters (CWL/FWHM) 575 nm,Filters can be purchased separately
4 - 6 Weeks $500.00
19006-Filter Set
19006-AT-Texas Red Longpass,Excitation tablets (CWL/FWHM) 560/40 nm, Dichroic mirrors(50% cut-on) 600 nm,Transmitters (CWL/FWHM) 610 nm,Filters can be purchased separately
4 - 6 Weeks $500.00
19008-Filter Set
19008-AT-Auramine Longpass,Excitation tablets (CWL/FWHM) 450/50 nm, Dichroic mirrors(50% cut-on) 485 nm,Transmitters (CWL/FWHM) 495 nm,Filters can be purchased separately
4 - 6 Weeks $500.00
19010-Filter Set
19010-A-FM 1-43/Chlorophyll Longpass,Excitation tablets (CWL/FWHM) 480/30 nm, Dichroic mirrors(50% cut-on) 505 nm,Transmitters (CWL/FWHM) 600 nm,Filters can be purchased separately
4 - 6 Weeks $500.00
19011-Filter Set
19011-AT–Coumarin/Pacific Blue Longpass,Excitation tablets (CWL/FWHM) 405/30 nm, Dichroic mirrors(50% cut-on) 440 nm,Transmitters (CWL/FWHM) 450 nm,Filters can be purchased separately
4 - 6 Weeks $500.00
19012-Filter Set
19012-AT–FluoroGold/Calcofluor White Longpass,Excitation tablets (CWL/FWHM) 375/28 nm, Dichroic mirrors(50% cut-on) 415 nm,Transmitters (CWL/FWHM) 515 nm,Filters can be purchased separately
4 - 6 Weeks $500.00
39101-Filter Set
39101-AT–Qdot 525,Excitation tablets (CWL/FWHM) 425/50 nm, Dichroic mirrors(50% cut-on) 485 nm,Transmitters (CWL/FWHM) 525/30 nm,Filters can be purchased separately
4 - 6 Weeks $575.00
39102-Filter Set
39102-AT-Qdot 545,Excitation tablets (CWL/FWHM) 425/50 nm, Dichroic mirrors(50% cut-on) 485 nm,Transmitters (CWL/FWHM) 545/30 nm,Filters can be purchased separately
4 - 6 Weeks $575.00
39103-Filter Set
39103-AT-Qdot 565,Excitation tablets (CWL/FWHM) 425/50 nm, Dichroic mirrors(50% cut-on) 485 nm,Transmitters (CWL/FWHM) 565/30 nm,Filters can be purchased separately
4 - 6 Weeks $575.00
39104-Filter Set
39104-AT–Qdot 585,Excitation tablets (CWL/FWHM) 425/50 nm, Dichroic mirrors(50% cut-on) 485 nm,Transmitters (CWL/FWHM) 585/30 nm,Filters can be purchased separately
4 - 6 Weeks $575.00
39105-Filter Set
39105-AT–Qdot 605,Excitation tablets (CWL/FWHM) 425/50 nm, Dichroic mirrors(50% cut-on) 485 nm,Transmitters (CWL/FWHM) 605/30 nm,Filters can be purchased separately
4 - 6 Weeks $575.00
39106-Filter Set
39106-AT–Qdot 625,Excitation tablets (CWL/FWHM) 425/50 nm, Dichroic mirrors(50% cut-on) 485 nm,Transmitters (CWL/FWHM) 625/30 nm,Filters can be purchased separately
4 - 6 Weeks $575.00
39107-Filter Set
39107-AT–Qdot 655,Excitation tablets (CWL/FWHM) 425/50 nm, Dichroic mirrors(50% cut-on) 485 nm,Transmitters (CWL/FWHM) 655/30 nm,Filters can be purchased separately
4 - 6 Weeks $575.00
39108-Filter Set
39108-AT–Qdot 705,Excitation tablets (CWL/FWHM) 425/50 nm, Dichroic mirrors(50% cut-on) 485 nm,Transmitters (CWL/FWHM) 705/30 nm,Filters can be purchased separately
4 - 6 Weeks $575.00
39109-Filter Set
39100-AT–Qdot 800,Excitation tablets (CWL/FWHM) 425/50 nm, Dichroic mirrors(50% cut-on) 485 nm,Transmitters (CWL/FWHM) 800/40 nm,Filters can be purchased separately
4 - 6 Weeks $575.00
49000-Filter Set
49000-ET-DAPI,Excitation tablets (CWL/FWHM) 350/50 nm, Dichroic mirrors(50% cut-on) 400 nm,Transmitters (CWL/FWHM) 460/50 nm,Filters can be purchased separately
4 - 6 Weeks $725.00
49001-Filter Set
49001-ET-ECFP,Excitation tablets (CWL/FWHM) 436/20 nm, Dichroic mirrors(50% cut-on) 455 nm,Transmitters (CWL/FWHM) 480/40 nm,Filters can be purchased separately
4-6 Weeks $925.00
49002-Filter Set
49002-ET-EGFP (FITC/Cy2),Excitation tablets (CWL/FWHM) 470/40 nm, Dichroic mirrors(50% cut-on) 495 nm,Transmitters (CWL/FWHM) 525/50 nm,Filters can be purchased separately
4-6 Weeks $925.00
49003-Filter Set
49003-ET-EYFP,Excitation tablets (CWL/FWHM) 500/20 nm, Dichroic mirrors(50% cut-on) 515 nm,Transmitters (CWL/FWHM) 535/30 nm,Filters can be purchased separately
4-6 Weeks $925.00
49004-Filter Set
49004-ET-CY3/TRITC,Excitation tablets (CWL/FWHM) 545/25 nm, Dichroic mirrors(50% cut-on) 565 nm,Transmitters (CWL/FWHM) 605/70 nm,Filters can be purchased separately
4-6 Weeks $925.00
49005-Filter Set
49005-ET-DSRed (TRITC/Cy3),Excitation tablets (CWL/FWHM) 545/30 nm, Dichroic mirrors(50% cut-on) 570 nm,Transmitters (CWL/FWHM) 620/60 nm,Filters can be purchased separately
4-6 Weeks $925.00
49006-Filter Set
49006-ET-Cy5,Excitation tablets (CWL/FWHM) 620/60 nm, Dichroic mirrors(50% cut-on) 660 nm,Transmitters (CWL/FWHM) 700/75 nm,Filters can be purchased separately
4-6 Weeks $925.00
49007-Filter Set
49007-ET- Cy7,Excitation tablets (CWL/FWHM) 710/75 nm, Dichroic mirrors(50% cut-on) 760 nm,Transmitters (CWL/FWHM) 810/90 nm,Filters can be purchased separately
4-6 Weeks $925.00
49008-Filter Set
49008-ET-mCherry, Texas Red®,Excitation tablets (CWL/FWHM) 560/40 nm, Dichroic mirrors(50% cut-on) 585 nm,Transmitters (CWL/FWHM) 630/75 nm,Filters can be purchased separately
4-6 Weeks $925.00
49009-Filter Set
49009-ET-Cy5 Narrow Excitation,Excitation tablets (CWL/FWHM) 640/30 nm, Dichroic mirrors(50% cut-on) 660 nm,Transmitters (CWL/FWHM) 690/50 nm,Filters can be purchased separately
4-6 Weeks $925.00
49010-Filter Set
49010-ET-R&B Phycoerythrin/mOrange/mKO,Excitation tablets (CWL/FWHM) 546/10 nm, Dichroic mirrors(50% cut-on) 560 nm,Transmitters (CWL/FWHM) 585/40nm,Filters can be purchased separately
4-6 Weeks $925.00
49011-Filter Set
49011-ET-FITC/Alexa Fluor 488/Fluo3/Oregon Green,Excitation tablets (CWL/FWHM) 480/40 nm, Dichroic mirrors(50% cut-on) 510 nm,Transmitters (CWL/FWHM) 535/50 nm,Filters can be purchased separately
4-6 Weeks $925.00
49012-Filter Set
49012-ET-FITC/EGFP Longpass,Excitation tablets (CWL/FWHM) 480/40 nm, Dichroic mirrors(50% cut-on) 510 nm,Transmitters (CWL/FWHM) 510 nm,Filters can be purchased separately
4-6 Weeks $925.00
49013-Filter Set
49013-ET-TFP (Teal FP),Excitation tablets (CWL/FWHM) 445/30 nm, Dichroic mirrors(50% cut-on) 470 nm,Transmitters (CWL/FWHM) 500/40nm,Filters can be purchased separately
4-6 Weeks $925.00
49014-Filter Set
49014-ET-mKO/mOrange,Excitation tablets (CWL/FWHM) 530/30 nm, Dichroic mirrors(50% cut-on) 550 nm,Transmitters (CWL/FWHM) 575/40 nm,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $925.00
49015-Filter Set
49015-ET-AlexaFluor 633,Excitation tablets (CWL/FWHM) 605/50 nm, Dichroic mirrors(50% cut-on) 635 nm,Transmitters (CWL/FWHM) 670/50 nm,Filters can be purchased separately
4-6 Weeks $925.00
49016-Filter Set
49016-ET-Cy3/TRITC Longpass,Excitation tablets (CWL/FWHM) 545/25 nm, Dichroic mirrors(50% cut-on) 562 nm,Transmitters (CWL/FWHM) 570 nm,Filters can be purchased separately
4-6 Weeks $925.00
49017-Filter Set
49017-ET-mCherry/Texas Red Longpass,Excitation tablets (CWL/FWHM) 560/40 nm, Dichroic mirrors(50% cut-on) 590 nm,Transmitters (CWL/FWHM) 590 nm,Filters can be purchased separately
4-6 Weeks $925.00
49018-Filter Set
49018-ET-EGFP Longpass,Excitation tablets (CWL/FWHM) 470/40 nm, Dichroic mirrors(50% cut-on) 495 nm,Transmitters (CWL/FWHM) 500 nm,Filters can be purchased separately
4-6 Weeks $925.00
49019-Filter Set
49019-ET- Cy5 Longpass,Excitation tablets (CWL/FWHM) 620/60 nm, Dichroic mirrors(50% cut-on) 660 nm,Transmitters (CWL/FWHM) 665 nm,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $925.00
49020-Filter Set
49020-ET-Narrow Band EGFP to Minimize Autofluorescence,Excitation tablets (CWL/FWHM) 480/20 nm, Dichroic mirrors(50% cut-on) 495 nm,Transmitters (CWL/FWHM) 510/20 nm,Filters can be purchased separately
4-6 Weeks $925.00
49021-Filter Set
49021-ET-EBFP2/Coumarin/Attenuated DAPI,Excitation tablets (CWL/FWHM) 405/20 nm, Dichroic mirrors(50% cut-on) 425 nm,Transmitters (CWL/FWHM) 460/50 nm,Filters can be purchased separately
4-6 Weeks $925.00
49022-Filter Set
49022-ET-Cy5.5,Excitation tablets (CWL/FWHM) 650/45 nm, Dichroic mirrors(50% cut-on) 685 nm,Transmitters (CWL/FWHM) 720/60 nm,Filters can be purchased separately
4-6 Weeks $925.00
49023-Filter Set
49023-ET-AlexaFluor 514/ZsYellow/Eosin,Excitation tablets (CWL/FWHM) 500/40 nm, Dichroic mirrors(50% cut-on) 525 nm,Transmitters (CWL/FWHM) 560/50 nm,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $925.00
49024-Filter Set
49024-ET-Keima Red/DiA,Excitation tablets (CWL/FWHM) 440/40 nm, Dichroic mirrors(50% cut-on) 495 nm,Transmitters (CWL/FWHM) 630/75 nm,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $925.00
49025-Filter Set
49025-ET-DAPI/FluoroGold Longpass,Excitation tablets (CWL/FWHM) 350/50 nm, Dichroic mirrors(50% cut-on) 400 nm,Transmitters (CWL/FWHM) 425 nm,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $925.00
49026-Filter Set
49026-ET-Tetracycline,Excitation tablets (CWL/FWHM) 405/40 nm, Dichroic mirrors(50% cut-on) 470 nm,Transmitters (CWL/FWHM) 550/60 nm,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $925.00
49027-Filter Set
49027-ET-Brilliant™ Violet 421, Alexa Fluor 405,Excitation tablets (CWL/FWHM) 395/25 nm, Dichroic mirrors(50% cut-on)412 nm,Transmitters (CWL/FWHM) 431/28 nm,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $925.00
49028-Filter Set
49028-ET-DAPI for 395nm light sources,Excitation tablets (CWL/FWHM) 395/25 nm, Dichroic mirrors(50% cut-on) 425 nm,Transmitters (CWL/FWHM) 460/50 nm,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $925.00
49029-Filter Set
49029-ET-EYFP Longpass,Excitation tablets (CWL/FWHM) 500/20 nm, Dichroic mirrors(50% cut-on) 515 nm,Transmitters (CWL/FWHM) 520 nm,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $925.00
49030-Filter Set
49030-ET-Indocyanine Green,Excitation tablets (CWL/FWHM) 775/50 nm, Dichroic mirrors(50% cut-on) 810 nm,Transmitters (CWL/FWHM) 845/55 nm,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $925.00
49031-Filter Set
49031-ET-Alexa Fluor 568, Cy3.5,Excitation tablets (CWL/FWHM) 569/25 nm, Dichroic mirrors(50% cut-on) 588 nm,Transmitters (CWL/FWHM) 615/40 nm,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $925.00
49032-Filter Set
49032-ET-Brilliant™ Violet 480,Excitation tablets (CWL/FWHM) 436/20 nm, Dichroic mirrors(50% cut-on) 455 nm,Transmitters (CWL/FWHM) 480/30 nm,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $925.00
49037-Filter Set
49037-ET-Li_Cor for IR dye 800,Excitation tablets (CWL/FWHM) 740/40 nm, Dichroic mirrors(50% cut-on) 770 nm,Transmitters (CWL/FWHM) 780 nm,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $925.00
T412lpxt
Dichroic beamsplitters (mirrors),Wavelength (CWL): 412 nm,Type :BS,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $250.00
AT415DC
Dichroic beamsplitters (mirrors),Wavelength (CWL): 415 nm,Type :BS,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $175.00
AT440DC
Dichroic beamsplitters (mirrors),Wavelength (CWL): 440 nm,Type :BS,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $175.00
T470lpxr
Dichroic beamsplitters (mirrors),Wavelength (CWL): 470 nm,Type :BS,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $250.00
AT485DC
Dichroic beamsplitters (mirrors),Wavelength (CWL): 485 nm,Type :BS,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $175.00
T495lpxr
Dichroic beamsplitters (mirrors),Wavelength (CWL): 495 nm,Type :BS,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $250.00
T495lpxt
Dichroic beamsplitters (mirrors),Wavelength (CWL): 495 nm,Type :BS,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $300.00
T510lpxrxt
Dichroic beamsplitters (mirrors),Wavelength (CWL): 510 nm,Type :BS,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $300.00
T525lpxr
Dichroic beamsplitters (mirrors),Wavelength (CWL): 525 nm,Type :BS,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $250.00
T550lpxr
Dichroic beamsplitters (mirrors),Wavelength (CWL): 550nm,Type :BS,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $250.00
T560lpxr
Dichroic beamsplitters (mirrors),Wavelength (CWL): 560 nm,Type :BS,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $250.00
T562lpxr
Dichroic beamsplitters (mirrors),Wavelength (CWL):562 nm,Type :BS,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $250.00
T570lp
Dichroic beamsplitters (mirrors),Wavelength (CWL): 570 nm,Type :BS,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $250.00
T570lpxr
Dichroic beamsplitters (mirrors),Wavelength (CWL): 570 nm,Type :BS,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $250.00
T585lpxr
Dichroic beamsplitters (mirrors),Wavelength (CWL): 585 nm,Type :BS,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $250.00
T588lpxr
Dichroic beamsplitters (mirrors),Wavelength (CWL): 588 nm,Type :BS,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $250.00
T590lpxr
Dichroic beamsplitters (mirrors),Wavelength (CWL): 590 nm,Type :BS,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $250.00
T635lpxr
Dichroic beamsplitters (mirrors),Wavelength (CWL): 635 nm,Type :BS,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $250.00
AT655DC
Dichroic beamsplitters (mirrors),Wavelength (CWL): 655 nm,Type :BS,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $175.00
T660lpxr
Dichroic beamsplitters (mirrors),Wavelength (CWL): 660 nm,Type :BS,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $250.00
T685lpxr
Dichroic beamsplitters (mirrors),Wavelength (CWL): 685 nm,Type :BS,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $250.00
T760lpxr
Dichroic beamsplitters (mirrors),Wavelength (CWL): 760 nm,Type :BS,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $250.00
T770lpxr
Dichroic beamsplitters (mirrors),Wavelength (CWL): 770 nm,Type :BS,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $250.00
T810lpxr
Dichroic beamsplitters (mirrors),Wavelength (CWL): 810 nm,Type :BS,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $250.00
T425lpxr
Dichroic beamsplitters (mirrors),Wavelength (CWL): 425 nm,Type :BS,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $250.00
T455lp
Dichroic beamsplitters (mirrors),Wavelength (CWL): 455 nm,Type :BS,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $250.00
AT505DC
Dichroic beamsplitters (mirrors),Wavelength (CWL): 505 nm,Type :BS,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $175.00
T515lp
Dichroic beamsplitters (mirrors),Wavelength (CWL): 515 nm,Type :BS,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $250.00
T565lpxr
Dichroic beamsplitters (mirrors),Wavelength (CWL): 565 nm,Type :BS,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $250.00
AT600DC
Dichroic beamsplitters (mirrors),Wavelength (CWL): 600 nm,Type :BS,Prices do not include any shipping, tax or customs clearance charges
4-6 Weeks $175.00

AT600DC - Parameter

T565lpxr - Parameter

T515lp - Parameter

AT505DC - Parameter

T455lp - Parameter

T425lpxr - Parameter

T810lpxr - Parameter

T770lpxr - Parameter

T760lpxr - Parameter

T685lpxr - Parameter

T660lpxr - Parameter

AT655DC - Parameter

T635lpxr - Parameter

T590lpxr - Parameter

T588lpxr - Parameter

T585lpxr - Parameter

T570lpxr - Parameter

T570lp - Parameter

T562lpxr - Parameter

T560lpxr - Parameter

T550lpxr - Parameter

T525lpxr - Parameter

T510lpxrxt - Parameter

T495lpxt - Parameter

T495lpxr - Parameter

AT485DC - Parameter

T470lpxr - Parameter

AT440DC - Parameter

AT415DC - Parameter

T412lpxt - Parameter

49037-Filter Set - Parameter

49032-Filter Set - Parameter

49031-Filter Set - Parameter

49030-Filter Set - Parameter

49029-Filter Set - Parameter

49028-Filter Set - Parameter

49027-Filter Set - Parameter

49026-Filter Set - Parameter

49025-Filter Set - Parameter

49024-Filter Set - Parameter

49023-Filter Set - Parameter

49022-Filter Set - Parameter

49021-Filter Set - Parameter

49020-Filter Set - Parameter

49019-Filter Set - Parameter

49018-Filter Set - Parameter

49017-Filter Set - Parameter

49016-Filter Set - Parameter

49015-Filter Set - Parameter

49014-Filter Set - Parameter

49013-Filter Set - Parameter

49012-Filter Set - Parameter

49011-Filter Set - Parameter

49010-Filter Set - Parameter

49009-Filter Set - Parameter

49008-Filter Set - Parameter

49007-Filter Set - Parameter

49006-Filter Set - Parameter

49005-Filter Set - Parameter

49004-Filter Set - Parameter

49003-Filter Set - Parameter

Type
Fluorescence Filters

Diameter (mm)
25.4

Diameter Tolerance (mm)
+0/-0.2

Thickness Tolerance (mm)
±0.1

Surface Quality
40-20

Chamfer
<0.5mmx45°

Thickness (mm)
6

Center Wavelength (nm)
470

Out-of-Band Blocking
200-1150nm

Bandwidth (FWHM) (nm)
35

Temperature Range
-20°C to +80°C

49002-Filter Set - Parameter

Type
Fluorescence Filters

Diameter (mm)
25.4

Diameter Tolerance (mm)
+0/-0.2

Thickness Tolerance (mm)
±0.1

Surface Quality
40-20

Chamfer
<0.5mmx45°

Thickness (mm)
6

Center Wavelength (nm)
470

Out-of-Band Blocking
200-1150nm

Bandwidth (FWHM) (nm)
20

Temperature Range
-20°C to +80°C

49001-Filter Set - Parameter

Type
Fluorescence Filters

Diameter (mm)
25.4

Diameter Tolerance (mm)
+0/-0.2

Thickness Tolerance (mm)
±0.1

Surface Quality
40-20

Chamfer
<0.5mmx45°

Thickness (mm)
6

Center Wavelength (nm)
470

Out-of-Band Blocking
200-1150nm

Bandwidth (FWHM) (nm)
10

Temperature Range
-20°C to +80°C

49000-Filter Set - Parameter

Type
Fluorescence Filters

Diameter (mm)
25.4

Diameter Tolerance (mm)
+0/-0.2

Thickness Tolerance (mm)
±0.1

Surface Quality
40-20

Chamfer
<0.5mmx45°

Thickness (mm)
6

Center Wavelength (nm)
450

Out-of-Band Blocking
200-1150nm

Bandwidth (FWHM) (nm)
35

Temperature Range
-20°C to +80°C

39109-Filter Set - Parameter

Type
Fluorescence Filters

Diameter (mm)
25.4

Diameter Tolerance (mm)
+0/-0.2

Thickness Tolerance (mm)
±0.1

Surface Quality
40-20

Chamfer
<0.5mmx45°

Thickness (mm)
6

Center Wavelength (nm)
405

Out-of-Band Blocking
200-1150nm

Bandwidth (FWHM) (nm)
35

Temperature Range
-20°C to +80°C

39108-Filter Set - Parameter

Type
Fluorescence Filters

Diameter (mm)
25.4

Diameter Tolerance (mm)
+0/-0.2

Thickness Tolerance (mm)
±0.1

Surface Quality
40-20

Chamfer
<0.5mmx45°

Thickness (mm)
6

Center Wavelength (nm)
365

Out-of-Band Blocking
200-1150nm

Bandwidth (FWHM) (nm)
35

Temperature Range
-20°C to +80°C

39107-Filter Set - Parameter

Type
Fluorescence Filters

Diameter (mm)
25.4

Diameter Tolerance (mm)
+0/-0.2

Thickness Tolerance (mm)
±0.1

Surface Quality
40-20

Chamfer
<0.5mmx45°

Thickness (mm)
6

Center Wavelength (nm)

Out-of-Band Blocking
200-1150nm

Bandwidth (FWHM) (nm)
20

Temperature Range
-20°C to +80°C

39106-Filter Set - Parameter

Type
Fluorescence Filters

Diameter (mm)
25.4

Diameter Tolerance (mm)
+0/-0.2

Thickness Tolerance (mm)
±0.1

Surface Quality
40-20

Chamfer
<0.5mmx45°

Thickness (mm)
6

Center Wavelength (nm)

Out-of-Band Blocking
200-1150nm

Bandwidth (FWHM) (nm)
20

Temperature Range
-20°C to +80°C

39105-Filter Set - Parameter

Type
Fluorescence Filters

Diameter (mm)
12.7

Diameter Tolerance (mm)
+0/-0.2

Thickness Tolerance (mm)
±0.1

Surface Quality
40-20

Chamfer
<0.5mmx45°

Thickness (mm)
6

Center Wavelength (nm)

Out-of-Band Blocking
200-1150nm

Bandwidth (FWHM) (nm)
40

Temperature Range
-20°C to +80°C

39104-Filter Set - Parameter

Type
Fluorescence Filters

Diameter (mm)
12.7

Diameter Tolerance (mm)
+0/-0.2

Thickness Tolerance (mm)
±0.1

Surface Quality
40-20

Chamfer
<0.5mmx45°

Thickness (mm)
6

Center Wavelength (nm)
650

Out-of-Band Blocking
200-1150nm

Bandwidth (FWHM) (nm)
40

Temperature Range
-20°C to +80°C

39103-Filter Set - Parameter

Type
Fluorescence Filters

Diameter (mm)
12.7

Diameter Tolerance (mm)
+0/-0.2

Thickness Tolerance (mm)
±0.1

Surface Quality
40-20

Chamfer
<0.5mmx45°

Thickness (mm)
6

Center Wavelength (nm)
630

Out-of-Band Blocking
200-1150nm

Bandwidth (FWHM) (nm)
40

Temperature Range
-20°C to +80°C

39102-Filter Set - Parameter

Type
Fluorescence Filters

Diameter (mm)
12.7

Diameter Tolerance (mm)
+0/-0.2

Thickness Tolerance (mm)
±0.1

Surface Quality
40-20

Chamfer
<0.5mmx45°

Thickness (mm)
6

Center Wavelength (nm)
620

Out-of-Band Blocking
200-1150nm

Bandwidth (FWHM) (nm)
40

Temperature Range
-20°C to +80°C

39101-Filter Set - Parameter

Type
Fluorescence Filters

Diameter (mm)
12.7

Diameter Tolerance (mm)
+0/-0.2

Thickness Tolerance (mm)
±0.1

Surface Quality
40-20

Chamfer
<0.5mmx45°

Thickness (mm)
6

Center Wavelength (nm)
590

Out-of-Band Blocking
200-1150nm

Bandwidth (FWHM) (nm)
40

Temperature Range
-20°C to +80°C

19012-Filter Set - Parameter

Type
Fluorescence Filters

Diameter (mm)
12.7

Diameter Tolerance (mm)
+0/-0.2

Thickness Tolerance (mm)
±0.1

Surface Quality
40-20

Chamfer
<0.5mmx45°

Thickness (mm)
6

Center Wavelength (nm)
570

Out-of-Band Blocking
200-1150nm

Bandwidth (FWHM) (nm)
40

Temperature Range
-20°C to +80°C

19011-Filter Set - Parameter

Type
Fluorescence Filters

Diameter (mm)
12.7

Diameter Tolerance (mm)
+0/-0.2

Thickness Tolerance (mm)
±0.1

Surface Quality
40-20

Chamfer
<0.5mmx45°

Thickness (mm)
6

Center Wavelength (nm)
550

Out-of-Band Blocking
200-1150nm

Bandwidth (FWHM) (nm)
40

Temperature Range
-20°C to +80°C

19010-Filter Set - Parameter

Type
Fluorescence Filters

Diameter (mm)
12.7

Diameter Tolerance (mm)
+0/-0.2

Thickness Tolerance (mm)
±0.1

Surface Quality
40-20

Chamfer
<0.5mmx45°

Thickness (mm)
6

Center Wavelength (nm)
550

Out-of-Band Blocking
200-1150nm

Bandwidth (FWHM) (nm)
15

Temperature Range
-20°C to +80°C

19008-Filter Set - Parameter

Type
Fluorescence Filters

Diameter (mm)
12.7

Diameter Tolerance (mm)
+0/-0.2

Thickness Tolerance (mm)
±0.1

Surface Quality
40-20

Chamfer
<0.5mmx45°

Thickness (mm)
6

Center Wavelength (nm)
530

Out-of-Band Blocking
200-1150nm

Bandwidth (FWHM) (nm)
35

Temperature Range
-20°C to +80°C

19006-Filter Set - Parameter

Type
Fluorescence Filters

Diameter (mm)
12.7

Diameter Tolerance (mm)
+0/-0.2

Thickness Tolerance (mm)
±0.1

Surface Quality
40-20

Chamfer
<0.5mmx45°

Thickness (mm)
6

Center Wavelength (nm)
530

Out-of-Band Blocking
200-1150nm

Bandwidth (FWHM) (nm)
15

Temperature Range
-20°C to +80°C

19004-Filter Set - Parameter

Type
Fluorescence Filters

Diameter (mm)
12.7

Diameter Tolerance (mm)
+0/-0.2

Thickness Tolerance (mm)
±0.1

Surface Quality
40-20

Chamfer
<0.5mmx45°

Thickness (mm)
6

Center Wavelength (nm)
520

Out-of-Band Blocking
200-1150nm

Bandwidth (FWHM) (nm)
20

Temperature Range
-20°C to +80°C

19002-Filter Set - Parameter

Type
Fluorescence Filters

Diameter (mm)
12.7

Diameter Tolerance (mm)
+0/-0.2

Thickness Tolerance (mm)
±0.1

Surface Quality
40-20

Chamfer
<0.5mmx45°

Thickness (mm)
6

Center Wavelength (nm)
520

Out-of-Band Blocking
200-1150nm

Bandwidth (FWHM) (nm)
10

Temperature Range
-20°C to +80°C

19001-Filter Set - Parameter

Type
Fluorescence Filters

Diameter (mm)
12.7

Diameter Tolerance (mm)
+0/-0.2

Thickness Tolerance (mm)
±0.1

Surface Quality
40-20

Chamfer
<0.5mmx45°

Thickness (mm)
6

Center Wavelength (nm)
510

Out-of-Band Blocking
200-1150nm

Bandwidth (FWHM) (nm)
20

Temperature Range
-20°C to +80°C

19000-Filter Set - Parameter

Type
Fluorescence Filters

Diameter (mm)
12.7

Diameter Tolerance (mm)
+0/-0.2

Thickness Tolerance (mm)
±0.1

Surface Quality
40-20

Chamfer
<0.5mmx45°

Thickness (mm)
6

Center Wavelength (nm)
510

Out-of-Band Blocking
200-1150nm

Bandwidth (FWHM) (nm)
15

Temperature Range
-20°C to +80°C

39010-Filter Set - Parameter

Type
Fluorescence Filters

Diameter (mm)
12.7

Diameter Tolerance (mm)
+0/-0.2

Thickness Tolerance (mm)
±0.1

Surface Quality
40-20

Chamfer
<0.5mmx45°

Thickness (mm)
6

Center Wavelength (nm)
480

Out-of-Band Blocking
200-1150nm

Bandwidth (FWHM) (nm)
20

Temperature Range
-20°C to +80°C

39009-Filter Set - Parameter

Type
Fluorescence Filters

Diameter (mm)
12.7

Diameter Tolerance (mm)
+0/-0.2

Thickness Tolerance (mm)
±0.1

Surface Quality
40-20

Chamfer
<0.5mmx45°

Thickness (mm)
6

Center Wavelength (nm)
480

Out-of-Band Blocking
200-1150nm

Bandwidth (FWHM) (nm)
10

Temperature Range
-20°C to +80°C

39008-Filter Set - Parameter

Type
Fluorescence Filters

Diameter (mm)
12.7

Diameter Tolerance (mm)
+0/-0.2

Thickness Tolerance (mm)
±0.1

Surface Quality
40-20

Chamfer
<0.5mmx45°

Thickness (mm)
6

Center Wavelength (nm)
470

Out-of-Band Blocking
200-1150nm

Bandwidth (FWHM) (nm)
35

Temperature Range
-20°C to +80°C

39007-Filter Set - Parameter

Type
Fluorescence Filters

Diameter (mm)
12.7

Diameter Tolerance (mm)
+0/-0.2

Thickness Tolerance (mm)
±0.1

Surface Quality
40-20

Chamfer
<0.5mmx45°

Thickness (mm)
6

Center Wavelength (nm)
470

Out-of-Band Blocking
200-1150nm

Bandwidth (FWHM) (nm)
20

Temperature Range
-20°C to +80°C

39005-Filter Set - Parameter

Type
Fluorescence Filters

Diameter (mm)
12.7

Diameter Tolerance (mm)
+0/-0.2

Thickness Tolerance (mm)
±0.1

Surface Quality
40-20

Chamfer
<0.5mmx45°

Thickness (mm)
6

Center Wavelength (nm)
470

Out-of-Band Blocking
200-1150nm

Bandwidth (FWHM) (nm)
10

Temperature Range
-20°C to +80°C

39004-Filter Set - Parameter

Type
Fluorescence Filters

Diameter (mm)
12.7

Diameter Tolerance (mm)
+0/-0.2

Thickness Tolerance (mm)
±0.1

Surface Quality
40-20

Chamfer
<0.5mmx45°

Thickness (mm)
6

Center Wavelength (nm)
450

Out-of-Band Blocking
200-1150nm

Bandwidth (FWHM) (nm)
35

Temperature Range
-20°C to +80°C

39003-Filter Set - Parameter

Type
Fluorescence Filters

Diameter (mm)
12.7

Diameter Tolerance (mm)
+0/-0.2

Thickness Tolerance (mm)
±0.1

Surface Quality
40-20

Chamfer
<0.5mmx45°

Thickness (mm)
6

Center Wavelength (nm)
405

Out-of-Band Blocking
200-1150nm

Bandwidth (FWHM) (nm)
35

Temperature Range
-20°C to +80°C

39002-Filter Set - Parameter

Type
Fluorescence Filters

Diameter (mm)
12.7

Diameter Tolerance (mm)
+0/-0.2

Thickness Tolerance (mm)
±0.1

Surface Quality
40-20

Chamfer
<0.5mmx45°

Thickness (mm)
6

Center Wavelength (nm)
365

Out-of-Band Blocking
200-1150nm

Bandwidth (FWHM) (nm)
35

Temperature Range
-20°C to +80°C

39001-Filter Set - Parameter

Type
Fluorescence Filters

Diameter (mm)
12.7

Diameter Tolerance (mm)
+0/-0.2

Thickness Tolerance (mm)
±0.1

Surface Quality
40-20

Chamfer
<0.5mmx45°

Thickness (mm)
6

Center Wavelength (nm)

Out-of-Band Blocking
200-1150nm

Bandwidth (FWHM) (nm)
20

Temperature Range
-20°C to +80°C

39000-Filter Set - Parameter

Type
Fluorescence Filters

Diameter (mm)
12.7

Diameter Tolerance (mm)
+0/-0.2

Thickness Tolerance (mm)
±0.1

Surface Quality
40-20

Chamfer
<0.5mmx45°

Thickness (mm)
6

Center Wavelength (nm)

Out-of-Band Blocking
200-1150nm

Bandwidth (FWHM) (nm)
20

Temperature Range
-20°C to +80°C

AT600DC - Download

T565lpxr - Download

T515lp - Download

AT505DC - Download

T455lp - Download

T425lpxr - Download

T810lpxr - Download

T770lpxr - Download

T760lpxr - Download

T685lpxr - Download

T660lpxr - Download

AT655DC - Download

T635lpxr - Download

T590lpxr - Download

T588lpxr - Download

T585lpxr - Download

T570lpxr - Download

T570lp - Download

T562lpxr - Download

T560lpxr - Download

T550lpxr - Download

T525lpxr - Download

T510lpxrxt - Download

T495lpxt - Download

T495lpxr - Download

AT485DC - Download

T470lpxr - Download

AT440DC - Download

AT415DC - Download

T412lpxt - Download

49037-Filter Set - Download

49032-Filter Set - Download

49031-Filter Set - Download

49030-Filter Set - Download

49029-Filter Set - Download

49028-Filter Set - Download

49027-Filter Set - Download

49026-Filter Set - Download

49025-Filter Set - Download

49024-Filter Set - Download

49023-Filter Set - Download

49022-Filter Set - Download

49021-Filter Set - Download

49020-Filter Set - Download

49019-Filter Set - Download

49018-Filter Set - Download

49017-Filter Set - Download

49016-Filter Set - Download

49015-Filter Set - Download

49014-Filter Set - Download

49013-Filter Set - Download

49012-Filter Set - Download

49011-Filter Set - Download

49010-Filter Set - Download

49009-Filter Set - Download

49008-Filter Set - Download

49007-Filter Set - Download

49006-Filter Set - Download

49005-Filter Set - Download

49004-Filter Set - Download

49003-Filter Set - Download

49002-Filter Set - Download

49001-Filter Set - Download

49000-Filter Set - Download

39109-Filter Set - Download

39108-Filter Set - Download

39107-Filter Set - Download

39106-Filter Set - Download

39105-Filter Set - Download

39104-Filter Set - Download

39103-Filter Set - Download

39102-Filter Set - Download

39101-Filter Set - Download

19012-Filter Set - Download

19011-Filter Set - Download

19010-Filter Set - Download

19008-Filter Set - Download

19006-Filter Set - Download

19004-Filter Set - Download

19002-Filter Set - Download

19001-Filter Set - Download

19000-Filter Set - Download

39010-Filter Set - Download

39009-Filter Set - Download

39008-Filter Set - Download

39007-Filter Set - Download

39005-Filter Set - Download

39004-Filter Set - Download

39003-Filter Set - Download

39002-Filter Set - Download

39001-Filter Set - Download

39000-Filter Set - Download

Accessories

Compare Model Drawings & Specs Availability Reference Price
(USD)
