Products / 光学元件 /视觉镜头 /变焦镜头 /Z125系列变焦镜头 / STPM-Z125D /

STPM-Z125D，Type Detented Zoom Lens，Optical Magnification Range 0.58X~7.5X，Working Distance 84±2mm，Zoom Control Manual Zoom

MODEL:STPM-Z125D

4-6 Weeks Drawings

Compare

Save To My List

* The prices are indicative only. Please contact us for an official quote. This is single product page, for detail specification please refer to product main page

Related Products Detailed Introduction

	Availability	Reference Price
STPM-Z125D-C STPM-Z125D-C，Type Detented with Coaxial llumination Zoom Lens，Optical Magnification Range 0.58X~7.5X，Working Distance 84±2mm，Zoom Control Manual Zoom	4-6 Weeks	Request for quote
STPM-Z125M/C STPM-Z125M/C，Type Motorized With Coaxial lllumination，Optical Magnification Range 0.58X~7.5X，Working Distance 84±2mm，Zoom Control Motorized zoom	4-6 Weeks	Request for quote
STPM-Z125M STPM-Z125M，Type Detented Zoom Lens，Optical Magnification Range 0.58X~7.5X，Working Distance 84±2mm，Zoom Control Motorized zoom	4-6 Weeks	Request for quote

Compatible

Compare	Model		Drawings & Specs	Availability	Reference Price

Product specifications and Brochures

Product Brochure Link:

Model		STPM-Z125M				STPM-Z125M/C				STPM-Z125D-C				STPM-Z125D
Type		Detented Zoom Lens				Motorized With Coaxial lllumination				Detented with Coaxial llumination Zoom Lens				Detented Zoom Lens
Optical Magnification Range		0.58X~7.5X
Working Distance		84±2mm
Optical Magnification		0.58X	0.6X	1X	1.5X	2X	2.5X	3X	3.5X	4X	4.5X	5X	5.5X	6X	6.5X	7X	7.5X
Depth of View (mm)		2.75	2.67	0.95	0.43	0.27	0.2	0.15	0.12	0.1	0.081	0.073	0.066	0.061	0.056	0.052	0.05
N.A.		0.025	0.025	0.043	0.063	0.074	0.082	0.09	0.097	0.1	0.11	0.11	0.11	0.11	0.11	0.11	0.11
F .No.		12.5	12.5	11.85	11. 95	13.65	15.3	16.5	18.4	19.9	20.4	22.45	22.7	26.8	29.4	31.7	33.9
Resolution(um)		13	13	7.8	5.3	4.53	4.09	3.73	3.46	3.36	3.05	3.05	3.05	3.05	3.05	3.05	3.05
TV Distortion		0.050%	0.050%	0.002%	0.010%	0.020%	0.003%	0.020%	0.020%	0.018%	0.020%	0.010%	0.010%	0.001%	0.010%	0.005%	0.005%
Field of View(DxHxV) (mm)	Diagonal	18.97	18.33	11	7.33	5.5	4.4	3.67	3.14	2.75	2.44	2.2	2	1.83	1.69	1.57	1.47
	Horizontal	15.17	14.67	8.8	5.87	4.4	3.52	2.93	2.51	2.2	1.96	1.76	1.6	1.47	1.35	1.26	1.17
	vertical	11.38	11	6.6	4.4	3.3	2.64	2.2	1.89	1.65	1.47	1.32	1.2	1.1	1.02	0.94	0.88
Max.Sensor Size		2/3"
Mount		C-Mount
Zoom Control		Motorized Zoom								Manual Zoom
