Products / 显微镜 /数字显微镜 /USB数字显微镜-带平台 / HP02000KPA /

USB Digital Microscope with Platform - HP Series, sensor 2.0Mega pixels, color mode Polychrome, FPS 17@1920X1080, exposure 0.105ms ~15s

MODEL:HP02000KPA

2-3 Weeks Drawings

Compare

Save To My List

* The prices are indicative only. Please contact us for an official quote. This is single product page, for detail specification please refer to product main page

Related Products Detailed Introduction

	Availability	Reference Price
CZB01200KPA-ZPA601200A USB Digital Microscope with Platform - CZ Series, zoom lens 0.25x~1.6x(continues and parfocal), sensor 1.2Mega pixels, color mode Monochrome, FPS 28@1280x960, exposure 0.4ms ~ 2000ms	In Stock	$10.00
CZB05100KPA-ZPA605100A USB Digital Microscope with Platform - CZ Series, zoom lens 0.7x~5.6x(continues and parfocal), sensor 5.1Mega pixels, color mode Polychrome, FPS 5@2592x1944, exposure 0.294ms ~ 2000ms	In Stock	$10.00
CZA01200KPA-ZPA601200A USB Digital Microscope with Platform - CZ Series, zoom lens 0.1x~1.6x(continues and parfocal), sensor 1.2Mega pixels, color mode Monochrome, FPS 28@1280x960, exposure 0.4ms ~ 2000ms	In Stock	$10.00
CZA05100KPA-ZPA605100A USB Digital Microscope with Platform - CZ Series, zoom lens 0.25x~1.6x(continues and parfocal), sensor 5.1Mega pixels, color mode Polychrome, FPS 5@2592x1944, exposure 0.294ms ~ 2000ms	In Stock	$10.00
HP05100KPA USB Digital Microscope with Platform - HP Series, sensor 5.1Mega pixels, color mode Polychrome, FPS 26@2592X1944, exposure 0.1ms ~ 2000ms	2-3 Weeks	Request for quote
HP02100KPA USB Digital Microscope with Platform, sensor 2.1Mega pixels, color mode Polychrome, FPS 38@1920X1080, exposure 0.1ms ~ 2000ms	2-3 Weeks	Request for quote

Compatible

Compare	Model		Drawings & Specs	Availability	Reference Price

Product specifications and Brochures

Optical Specification for HP Series
Optical Lens	5G High Grade Optical Glass with Multi-layer Anti-reflection Coating
Optical Magnification	0.1x~3.3x(33x)
Working Distance	10mm~110mm
Illumination	8 LEDs Illumination
Stand	M-SD-HM5 with F41mm Holding Ring
Other Specification for HP Series
Spectral Range	380-650nm (with IR-cut Filter)
White Balance	Auto White Balance
Color Technique	Ultra-Fine Color Engine
Capture/Control SDK	Windows/Linux/macOS/Android Multiple Platform SDK(Native C/C++, C#/VB.NET, Python, Java, DirectShow, Twain, etc)
Recording System	Still Picture and Movie
Cooling System*	Natural
Operating Environment
Operating Temperature (in Centidegree)	-10~ 50
Storage Temperature (in Centidegree)	-20~ 60
Operating Humidity	30~80%RH
Storage Humidity	10~60%RH
Power Supply	DC 5V over PC USB Port
Software Environment
Operating System	Microsoft® Windows® XP / Vista / 7 / 8 /10 /11 (32 & 64 bit) OSx(Mac OS X) Linux
PC Requirements	CPU: Equal to Intel Core2 2.8GHz or Higher
	Memory: 2GB or More
	USB Port: USB3.0 High-speed Port
	Display: 17” or Larger
	CD-ROM

Optical Specification for HP Series
Optical Lens	5G High Grade Optical Glass with Multi-layer Anti-reflection Coating
Optical Magnification	0.1x~3.3x(33x)
Working Distance	10mm~110mm
Illumination	8 LEDs Illumination
Stand	M-SD-HM5 with F41mm Holding Ring

HP Series Model Guide

Order Code	Sensor	Size(mm)	Sensitivity	FPS/Resolution	Binning	Exposure
HP02000KPA	2.0M/IMX290(C) 1/2.8" (5.56x3.13)	2.9 x2.9	1300mv with 1/30s 0.15mv with 1/30s	17@1920x1080	1x1	0.105ms~15s
HP02100KPA	2.1M/IMX307(C) 1/2.8" (5.56x3.13)	2.9 x2.9	1300mv with 1/30s 0.15mv with 1/30s	38@1920x1080 38@960x540	1x1 1x1	0.1-2000 ms
HP05100KPA	5.1M/IMX335(C) 1/2.8" (5.18x3.89)	2.0x2.0	505mv with 1/30s 0.13mv with 1/30s	26@2592x1944 26@1280x960 26@640x480	1x1 1x1 1x1	0.1-2000 ms

* C: Color; M: Monochrome; Default shutter: Rolling Shutter

Magnification, Working Distance, and Field of View

Magnification	Work Distance	Field of View(X) mm	Field of View(Y) mm
10	134.63	48.09	27.07
20	73.65	24.05	13.54
30	50.85	16.03	9.02
40	40.39	12.02	6.77
50	33.51	9.62	5.41
60	29.3	8.02	4.51
70	26.02	6.87	3.87
80	23.76	6.01	3.38
90	21.84	5.34	3.01
100	20.32	4.81	2.71
110	19.18	4.37	2.46
120	18.14	4.01	2.26
130	17.33	3.7	2.08
140	16.58	3.44	1.93
150	15.97	3.21	1.8
160	15.4	3.01	1.69
170	14.9	2.83	1.59
180	14.49	2.67	1.5
190	14.09	2.53	1.42
200	13.75	2.4	1.35
210	13.43	2.29	1.29
220	13.15	2.19	1.23
230	12.88	2.09	1.18
240	12.65	2	1.13
250	12.42	1.92	1.08
260	12.21	1.85	1.04
270	12.03	1.78	1
280	11.85	1.72	0.97

Packing Information - HP Series

Standard Package
A	Carton L:45cm W:45cm H:48cm (20pcs, 17Kg/ carton), not shown in the photo
B	Gift box: L:22cm W:22cm H: 9cm (0.8Kg/box)
C	HP series microscope
D	CD (Driver & utilities software, Ø12cm)
